SPECIFICATIONS

Brand Name: ComWinTop
Certification: None
High-concerned chemical: None
Model Number: CWT-TVS
Origin: Mainland China
Smart home platform: Other

Introduction:

This temperature vibration sensor uses high-performance MEMS chips. Adopt embedded technology, temperature sensing technology and vibration sensing technology. It has the advantages of high performance, low power consumption and anti-interference. Widely used in motors, reducers, generators, air compressors, centrifuges, water pumps and other equipment temperature vibration measurement.



Specifications:

Power supply
DC10-30V
Protection class
IP67
Frequency range (HZ)
10-1600
Vibration measurement direction
1-axis or 3-axis
WorKing environment
-40℃~+80℃, 0%RH~80%RH
Vibration speed measurement range  (mm/s)
0-50
Vibration velocity measurement  accuracy (mm/s)
±1.5% FS (@1kHz, 10mm/s)
Vibration speed display resolution  (mm/s)
0.1
Surface temperature measurement range  (℃)
-40~+80
Temperature display resolution (℃)
0.1
Signal output
