Logic Analyzer Probe Adapter and Cable Set
Logic analyzer probe adapter and cable set designed for use with RIGOL mixed signal oscilloscopes and logic analyzers, enabling reliable multi-channel digital signal acquisition.
The RIGOL PLA2216 is a logic analyzer probe adapter and cable accessory designed to interface digital signals with compatible RIGOL mixed signal oscilloscopes and logic analyzer systems.
It provides a stable and convenient connection for capturing multi-channel digital logic signals, allowing engineers and technicians to analyze timing relationships, logic states, and protocol behavior alongside analog waveforms when used with supported RIGOL instruments.
The PLA2216 is suitable for development, debugging, education, and production test environments where reliable digital signal probing is required.
Key Applications
-
Mixed-signal debugging
-
Digital logic analysis
-
Embedded systems development
-
Protocol timing verification
-
Education and training laboratories
Key Features
-
Logic analyzer probe adapter and cable set
-
Designed for RIGOL logic analyzer and MSO platforms
-
Enables multi-channel digital signal capture
-
Compact and flexible cable design
-
Reliable electrical connection for logic-level signals
