Advanced Coating Thickness Gauge – 0–1250μm for Ferrous & Non-Ferrous Surfaces
Professional-grade coating thickness tester for fast, non-destructive measurements on automotive paint, metals, and industrial coatings. Dual-mode probe with wide range, high accuracy, and optional PC connectivity.
Set Includes:
- 1 x Coating Thickness Meter
- 4 x Calibration foils
- 1 x Aluminum substrates
- 1 x Iron substrates
- 1 x English Instruction Manual
- 1 x Sturdy & Protective Storage Case
Product Description
Specifications
Precision Coating Thickness Meter for Automotive, Paint & Metal Applications
Engineered for professionals in automotive, manufacturing, and quality control, this advanced coating thickness meter uses magnetic induction and eddy current principles to precisely measure coatings on both ferrous (F) and non-ferrous (NF) metal substrates. With a wide measurement range of 0–1250μm (0–50mil), it delivers quick, reliable, and non-destructive results for paint, film, plating, and more.
This rugged, microprocessor-controlled device automatically identifies substrate types and offers single or continuous measurement modes, with 99-group data storage, Max/Min/Average analysis, and optional PC data transfer via RS232 interface (cable/software sold separately).
Key Features & Benefits:
-
✅ Dual Technology – Ferrous & Non-Ferrous Probes:
Measures non-magnetic coatings on magnetic substrates (Fe) and insulating coatings on non-magnetic conductive materials (NFe) -
✅ Wide Measuring Range:
0–1250μm / 0–50mil for comprehensive coating inspection -
✅ Fast & Accurate Results:
Advanced LSI microprocessor with crystal time base ensures high-speed response and consistent accuracy -
✅ Automatic Substrate Recognition:
Auto-switches between Fe and NFe modes depending on material surface -
✅ Flexible Measurement Modes:
Supports single and continuous readings for better control -
✅ Data Storage & Statistics:
Stores up to 99 measurements, with Max, Min, Average analysis for quality control -
✅ Large Backlit LCD Display:
Easy-to-read results even in low-light conditions -
✅ Optional PC Connectivity:
RS232 interface allows data transfer to computer for logging and analysis (software/cable not included)
Ideal For:
Automotive paint inspection • Metal fabrication • Powder coating QA • Industrial surface analysis • Plating thickness validation
Achieve high precision in surface coating inspection – whether for automotive detailing or industrial QA – with this powerful, portable coating thickness meter.
