ProSight Micro Differential Pressure Transmitter & Controller – MEMS Sensor

The ProSight Micro Differential Pressure Transmitter & Controller – MEMS Sensor is an industrial measurement device designed to measure the difference in pressure between two separate pressure points and convert that measurement into a standardized electrical signal.

A differential pressure transmitter differs from a conventional pressure transmitter because it measures the difference between two pressures rather than measuring only one pressure relative to atmospheric pressure or a vacuum reference. This makes the ProSight Micro Differential Pressure Transmitter & Controller – MEMS Sensor particularly useful for monitoring pressure drops across filters, measuring flow through pressure-based systems, monitoring equipment performance, and maintaining pressure differences between controlled areas.

The transmitter has two pressure inputs, generally identified as the high-pressure (+) and low-pressure (-) sides. The internal sensing element detects the difference between these two pressures and the transmitter's electronics process the signal to provide a corresponding output for monitoring and control systems.

It can be integrated with PLCs, SCADA systems, HMIs, building management systems, data acquisition equipment, and industrial controllers, depending on the selected output configuration.

How Does It Work?

• The higher pressure is applied to the transmitter's high-pressure (+) port.
• The lower pressure is applied to the low-pressure (-) port.
• The internal differential pressure sensing element responds to the pressure difference between the two ports.
• The sensing element converts the pressure difference into an electrical signal.
• Internal electronic circuitry processes and conditions the sensor signal.
• The transmitter generates an output signal proportional to the measured differential pressure.
• The output can be connected to a PLC, SCADA system, HMI, BMS, data acquisition system, or other compatible control equipment.
• The measured pressure difference can then be used to monitor equipment operation, calculate flow, detect filter blockage, or maintain controlled pressure conditions.

Why Choose this Product?

• Accurate differential pressure measurement – Designed to provide reliable measurement of pressure differences between two points.
• Wide application range – Suitable for industrial process control, HVAC, cleanrooms, filtration, fluid systems, and equipment monitoring.
• Filter monitoring capability – Can be used to monitor pressure drops across filters and identify increasing resistance caused by contamination or blockage.
• Flow measurement support – Differential pressure measurements can be used with suitable primary flow elements to determine flow rate.
• Stable measurement performance – Designed for continuous monitoring applications.
• Multiple pressure range options – Allows selection of a suitable measurement range for different applications.
• Flexible output options – Available configurations can support integration with different industrial control architectures.
• Automation compatible – Suitable for connection to PLCs, SCADA, HMIs, and building management systems.
• Two-port differential measurement – Provides direct comparison between high- and low-pressure points.
• Compact industrial design – Suitable for equipment installations with limited space.
• Durable construction – Designed for continuous industrial use.
• Versatile installation – Can be used in a wide range of pressure monitoring applications.
• Suitable for OEM integration – Can be incorporated into specialized machinery and industrial equipment.

Benefits

• Provides continuous monitoring of pressure differences.
• Helps identify abnormal operating conditions.
• Supports early detection of clogged or blocked filters.
• Helps maintain desired pressure differences in controlled environments.
• Supports airflow and liquid-flow measurement systems.
• Enables automated process monitoring and control.
• Provides useful data for equipment diagnostics.
• Helps improve HVAC and ventilation system performance.
• Supports predictive and preventive maintenance strategies.
• Reduces reliance on manual pressure checks.
• Integrates with existing industrial automation infrastructure.
• Helps improve operational efficiency and system reliability.
• Suitable for a wide range of industrial and commercial applications.
